Klemmhebel mit Innengewinde

Artikelnummer: 06600_1

Produktinfo

Material
Handle in glass-fibre reinforced plastic with toothed wheel in die cast zinc. Steel parts quality class 5.8

Yta
Steel parts black oxide finish

Notera
DELTA Add the desired clamp lever colour here

Order No.	Colour	Size	Internal thread X	T	D	D2	H2	H3	H4	A	A1	B	No. of teeth	Approx. weight kg	X	Surface finish	D1	H	H1
06600-1041	anthracite grey	1	M4	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M4	steel parts in steel	13	24,5	4
06600-1042	orange	1	M4	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M4	steel parts in steel	13	24,5	4
06600-10416	bright yellow	1	M4	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M4	steel parts in steel	13	24,5	4
06600-10484	traffic red	1	M4	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M4	steel parts in steel	13	24,5	4
06600-10486	signal green	1	M4	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M4	steel parts in steel	13	24,5	4
06600-10487	traffic blue	1	M4	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M4	steel parts in steel	13	24,5	4
06600-1051	anthracite grey	1	M5	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M5	steel parts in steel	13	24,5	4
06600-1052	orange	1	M5	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M5	steel parts in steel	13	24,5	4
06600-10516	bright yellow	1	M5	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M5	steel parts in steel	13	24,5	4
06600-10584	traffic red	1	M5	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M5	steel parts in steel	13	24,5	4
06600-10586	signal green	1	M5	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M5	steel parts in steel	13	24,5	4
06600-10587	traffic blue	1	M5	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M5	steel parts in steel	13	24,5	4
06600-1061	anthracite grey	1	M6	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M6	steel parts in steel	13	24,5	4
06600-1062	orange	1	M6	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M6	steel parts in steel	13	24,5	4
06600-10616	bright yellow	1	M6	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M6	steel parts in steel	13	24,5	4
06600-10684	traffic red	1	M6	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M6	steel parts in steel	13	24,5	4
06600-10686	signal green	1	M6	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M6	steel parts in steel	13	24,5	4
06600-10687	traffic blue	1	M6	9	10	14,5	15	30	33,5	40	47	7,5	16	0,013	M6	steel parts in steel	13	24,5	4
06600-2061	anthracite grey	2	M6	12	13,5	19,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M6	steel parts in steel	18	28,5	6,5
06600-2062	orange	2	M6	12	13,5	19,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M6	steel parts in steel	18	28,5	6,5
06600-20616	bright yellow	2	M6	12	13,5	19,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M6	steel parts in steel	18	28,5	6,5
06600-20684	traffic red	2	M6	12	13,5	19,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M6	steel parts in steel	18	28,5	6,5
06600-20686	signal green	2	M6	12	13,5	19,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M6	steel parts in steel	18	28,5	6,5
06600-20687	traffic blue	2	M6	12	13,5	19,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M6	steel parts in steel	18	28,5	6,5
06600-2081	anthracite grey	2	M8	12	13,5	19,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M8	steel parts in steel	18	28,5	6,5
06600-2082	orange	2	M8	12	13,5	19,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M8	steel parts in steel	18	28,5	6,5
06600-20816	bright yellow	2	M8	12	13,5	19,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M8	steel parts in steel	18	28,5	6,5
06600-20884	traffic red	2	M8	12	13,5	19,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M8	steel parts in steel	18	28,5	6,5
06600-20886	signal green	2	M8	12	13,5	19,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M8	steel parts in steel	18	28,5	6,5
06600-20887	traffic blue	2	M8	12	13,5	19,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M8	steel parts in steel	18	28,5	6,5
06600-3081	anthracite grey	3	M8	14	16	23	24	53,5	58	80	91,5	11	22	0,050	M8	steel parts in steel	21,5	37	10
06600-3082	orange	3	M8	14	16	23	24	53,5	58	80	91,5	11	22	0,050	M8	steel parts in steel	21,5	37	10
06600-30816	bright yellow	3	M8	14	16	23	24	53,5	58	80	91,5	11	22	0,050	M8	steel parts in steel	21,5	37	10
06600-30884	traffic red	3	M8	14	16	23	24	53,5	58	80	91,5	11	22	0,050	M8	steel parts in steel	21,5	37	10
06600-30886	signal green	3	M8	14	16	23	24	53,5	58	80	91,5	11	22	0,050	M8	steel parts in steel	21,5	37	10
06600-30887	traffic blue	3	M8	14	16	23	24	53,5	58	80	91,5	11	22	0,050	M8	steel parts in steel	21,5	37	10
06600-3101	anthracite grey	3	M10	14	16	23	24	53,5	58	80	91,5	11	22	0,050	M10	steel parts in steel	21,5	37	10
06600-3102	orange	3	M10	14	16	23	24	53,5	58	80	91,5	11	22	0,050	M10	steel parts in steel	21,5	37	10
06600-31016	bright yellow	3	M10	14	16	23	24	53,5	58	80	91,5	11	22	0,050	M10	steel parts in steel	21,5	37	10
06600-31084	traffic red	3	M10	14	16	23	24	53,5	58	80	91,5	11	22	0,050	M10	steel parts in steel	21,5	37	10
06600-31086	signal green	3	M10	14	16	23	24	53,5	58	80	91,5	11	22	0,050	M10	steel parts in steel	21,5	37	10
06600-31087	traffic blue	3	M10	14	16	23	24	53,5	58	80	91,5	11	22	0,050	M10	steel parts in steel	21,5	37	10
06600-4101	anthracite grey	4	M10	17	19	27,5	26	61	66	95	109	13	24	0,078	M10	steel parts in steel	25,5	43	10
06600-4102	orange	4	M10	17	19	27,5	26	61	66	95	109	13	24	0,078	M10	steel parts in steel	25,5	43	10
06600-41016	bright yellow	4	M10	17	19	27,5	26	61	66	95	109	13	24	0,078	M10	steel parts in steel	25,5	43	10
06600-41084	traffic red	4	M10	17	19	27,5	26	61	66	95	109	13	24	0,078	M10	steel parts in steel	25,5	43	10
06600-41086	signal green	4	M10	17	19	27,5	26	61	66	95	109	13	24	0,078	M10	steel parts in steel	25,5	43	10
06600-41087	traffic blue	4	M10	17	19	27,5	26	61	66	95	109	13	24	0,078	M10	steel parts in steel	25,5	43	10
06600-4121	anthracite grey	4	M12	17	19	27,5	26	61	66	95	109	13	24	0,078	M12	steel parts in steel	25,5	43	10
06600-4122	orange	4	M12	17	19	27,5	26	61	66	95	109	13	24	0,078	M12	steel parts in steel	25,5	43	10
06600-41216	bright yellow	4	M12	17	19	27,5	26	61	66	95	109	13	24	0,078	M12	steel parts in steel	25,5	43	10
06600-41284	traffic red	4	M12	17	19	27,5	26	61	66	95	109	13	24	0,078	M12	steel parts in steel	25,5	43	10
06600-41286	signal green	4	M12	17	19	27,5	26	61	66	95	109	13	24	0,078	M12	steel parts in steel	25,5	43	10
06600-41287	traffic blue	4	M12	17	19	27,5	26	61	66	95	109	13	24	0,078	M12	steel parts in steel	25,5	43	10
06600-5121	anthracite grey	5	M12	23	23	32,5	33	72	77	110	126	15,5	26	0,130	M12	steel parts in steel	30	49	12
06600-5122	orange	5	M12	23	23	32,5	33	72	77	110	126	15,5	26	0,130	M12	steel parts in steel	30	49	12
06600-51216	bright yellow	5	M12	23	23	32,5	33	72	77	110	126	15,5	26	0,130	M12	steel parts in steel	30	49	12
06600-51284	traffic red	5	M12	23	23	32,5	33	72	77	110	126	15,5	26	0,130	M12	steel parts in steel	30	49	12
06600-51286	signal green	5	M12	23	23	32,5	33	72	77	110	126	15,5	26	0,130	M12	steel parts in steel	30	49	12
06600-51287	traffic blue	5	M12	23	23	32,5	33	72	77	110	126	15,5	26	0,130	M12	steel parts in steel	30	49	12
06600-5161	anthracite grey	5	M16	23	23	32,5	33	72	77	110	126	15,5	26	0,130	M16	steel parts in steel	30	49	12
06600-5162	orange	5	M16	23	23	32,5	33	72	77	110	126	15,5	26	0,130	M16	steel parts in steel	30	49	12
06600-51616	bright yellow	5	M16	23	23	32,5	33	72	77	110	126	15,5	26	0,130	M16	steel parts in steel	30	49	12
06600-51684	traffic red	5	M16	23	23	32,5	33	72	77	110	126	15,5	26	0,130	M16	steel parts in steel	30	49	12
06600-51686	signal green	5	M16	23	23	32,5	33	72	77	110	126	15,5	26	0,130	M16	steel parts in steel	30	49	12
06600-51687	traffic blue	5	M16	23	23	32,5	33	72	77	110	126	15,5	26	0,130	M16	steel parts in steel	30	49	12

Order No.	Colour	Size	Internal thread X	T	D	D1	D2	H	H1	H2	H3	H4	A	A1	B	No. of teeth	Approx. weight kg	X	Surface finish
06601-1041	anthracite grey	1	M4	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M4	steel parts in stainless steel
06601-1042	orange	1	M4	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M4	steel parts in stainless steel
06601-10416	bright yellow	1	M4	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M4	steel parts in stainless steel
06601-10484	traffic red	1	M4	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M4	steel parts in stainless steel
06601-10486	signal green	1	M4	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M4	steel parts in stainless steel
06601-10487	traffic blue	1	M4	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M4	steel parts in stainless steel
06601-1051	anthracite grey	1	M5	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M5	steel parts in stainless steel
06601-1052	orange	1	M5	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M5	steel parts in stainless steel
06601-10516	bright yellow	1	M5	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M5	steel parts in stainless steel
06601-10584	traffic red	1	M5	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M5	steel parts in stainless steel
06601-10586	signal green	1	M5	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M5	steel parts in stainless steel
06601-10587	traffic blue	1	M5	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M5	steel parts in stainless steel
06601-1061	anthracite grey	1	M6	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M6	steel parts in stainless steel
06601-1062	orange	1	M6	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M6	steel parts in stainless steel
06601-10616	bright yellow	1	M6	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M6	steel parts in stainless steel
06601-10684	traffic red	1	M6	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M6	steel parts in stainless steel
06601-10686	signal green	1	M6	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M6	steel parts in stainless steel
06601-10687	traffic blue	1	M6	9	10	13	14,5	24,5	4	15	30	33,5	40	47	7,5	16	0,013	M6	steel parts in stainless steel
06601-2061	anthracite grey	2	M6	12	13,5	18	19,5	28,5	6,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M6	steel parts in stainless steel
06601-2062	orange	2	M6	12	13,5	18	19,5	28,5	6,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M6	steel parts in stainless steel
06601-20616	bright yellow	2	M6	12	13,5	18	19,5	28,5	6,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M6	steel parts in stainless steel
06601-20684	traffic red	2	M6	12	13,5	18	19,5	28,5	6,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M6	steel parts in stainless steel
06601-20686	signal green	2	M6	12	13,5	18	19,5	28,5	6,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M6	steel parts in stainless steel
06601-20687	traffic blue	2	M6	12	13,5	18	19,5	28,5	6,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M6	steel parts in stainless steel
06601-2081	anthracite grey	2	M8	12	13,5	18	19,5	28,5	6,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M8	steel parts in stainless steel
06601-2082	orange	2	M8	12	13,5	18	19,5	28,5	6,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M8	steel parts in stainless steel
06601-20816	bright yellow	2	M8	12	13,5	18	19,5	28,5	6,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M8	steel parts in stainless steel
06601-20884	traffic red	2	M8	12	13,5	18	19,5	28,5	6,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M8	steel parts in stainless steel
06601-20886	signal green	2	M8	12	13,5	18	19,5	28,5	6,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M8	steel parts in stainless steel
06601-20887	traffic blue	2	M8	12	13,5	18	19,5	28,5	6,5	17,5	41,5	45,5	65	75	9,5	20	0,029	M8	steel parts in stainless steel
06601-3081	anthracite grey	3	M8	14	16	21,5	23	37	10	24	53,5	58	80	91,5	11	22	0,050	M8	steel parts in stainless steel
06601-3082	orange	3	M8	14	16	21,5	23	37	10	24	53,5	58	80	91,5	11	22	0,050	M8	steel parts in stainless steel
06601-30816	bright yellow	3	M8	14	16	21,5	23	37	10	24	53,5	58	80	91,5	11	22	0,050	M8	steel parts in stainless steel
06601-30884	traffic red	3	M8	14	16	21,5	23	37	10	24	53,5	58	80	91,5	11	22	0,050	M8	steel parts in stainless steel
06601-30886	signal green	3	M8	14	16	21,5	23	37	10	24	53,5	58	80	91,5	11	22	0,050	M8	steel parts in stainless steel
06601-30887	traffic blue	3	M8	14	16	21,5	23	37	10	24	53,5	58	80	91,5	11	22	0,050	M8	steel parts in stainless steel
06601-3101	anthracite grey	3	M10	14	16	21,5	23	37	10	24	53,5	58	80	91,5	11	22	0,050	M10	steel parts in stainless steel
06601-3102	orange	3	M10	14	16	21,5	23	37	10	24	53,5	58	80	91,5	11	22	0,050	M10	steel parts in stainless steel
06601-31016	bright yellow	3	M10	14	16	21,5	23	37	10	24	53,5	58	80	91,5	11	22	0,050	M10	steel parts in stainless steel
06601-31084	traffic red	3	M10	14	16	21,5	23	37	10	24	53,5	58	80	91,5	11	22	0,050	M10	steel parts in stainless steel
06601-31086	signal green	3	M10	14	16	21,5	23	37	10	24	53,5	58	80	91,5	11	22	0,050	M10	steel parts in stainless steel
06601-31087	traffic blue	3	M10	14	16	21,5	23	37	10	24	53,5	58	80	91,5	11	22	0,050	M10	steel parts in stainless steel
06601-4101	anthracite grey	4	M10	17	19	25,5	27,5	43	10	26	61	66	95	109	13	24	0,078	M10	steel parts in stainless steel
06601-4102	orange	4	M10	17	19	25,5	27,5	43	10	26	61	66	95	109	13	24	0,078	M10	steel parts in stainless steel
06601-41016	bright yellow	4	M10	17	19	25,5	27,5	43	10	26	61	66	95	109	13	24	0,078	M10	steel parts in stainless steel
06601-41084	traffic red	4	M10	17	19	25,5	27,5	43	10	26	61	66	95	109	13	24	0,078	M10	steel parts in stainless steel
06601-41086	signal green	4	M10	17	19	25,5	27,5	43	10	26	61	66	95	109	13	24	0,078	M10	steel parts in stainless steel
06601-41087	traffic blue	4	M10	17	19	25,5	27,5	43	10	26	61	66	95	109	13	24	0,078	M10	steel parts in stainless steel
06601-4121	anthracite grey	4	M12	17	19	25,5	27,5	43	10	26	61	66	95	109	13	24	0,078	M12	steel parts in stainless steel
06601-4122	orange	4	M12	17	19	25,5	27,5	43	10	26	61	66	95	109	13	24	0,078	M12	steel parts in stainless steel
06601-41216	bright yellow	4	M12	17	19	25,5	27,5	43	10	26	61	66	95	109	13	24	0,078	M12	steel parts in stainless steel
06601-41284	traffic red	4	M12	17	19	25,5	27,5	43	10	26	61	66	95	109	13	24	0,078	M12	steel parts in stainless steel
06601-41286	signal green	4	M12	17	19	25,5	27,5	43	10	26	61	66	95	109	13	24	0,078	M12	steel parts in stainless steel
06601-41287	traffic blue	4	M12	17	19	25,5	27,5	43	10	26	61	66	95	109	13	24	0,078	M12	steel parts in stainless steel
06601-5121	anthracite grey	5	M12	23	23	30	32,5	49	12	33	72	77	110	126	15,5	26	0,130	M12	steel parts in stainless steel
06601-5122	orange	5	M12	23	23	30	32,5	49	12	33	72	77	110	126	15,5	26	0,130	M12	steel parts in stainless steel
06601-51216	bright yellow	5	M12	23	23	30	32,5	49	12	33	72	77	110	126	15,5	26	0,130	M12	steel parts in stainless steel
06601-51284	traffic red	5	M12	23	23	30	32,5	49	12	33	72	77	110	126	15,5	26	0,130	M12	steel parts in stainless steel
06601-51286	signal green	5	M12	23	23	30	32,5	49	12	33	72	77	110	126	15,5	26	0,130	M12	steel parts in stainless steel
06601-51287	traffic blue	5	M12	23	23	30	32,5	49	12	33	72	77	110	126	15,5	26	0,130	M12	steel parts in stainless steel
06601-5161	anthracite grey	5	M16	23	23	30	32,5	49	12	33	72	77	110	126	15,5	26	0,130	M16	steel parts in stainless steel
06601-5162	orange	5	M16	23	23	30	32,5	49	12	33	72	77	110	126	15,5	26	0,130	M16	steel parts in stainless steel
06601-51616	bright yellow	5	M16	23	23	30	32,5	49	12	33	72	77	110	126	15,5	26	0,130	M16	steel parts in stainless steel
06601-51684	traffic red	5	M16	23	23	30	32,5	49	12	33	72	77	110	126	15,5	26	0,130	M16	steel parts in stainless steel
06601-51686	signal green	5	M16	23	23	30	32,5	49	12	33	72	77	110	126	15,5	26	0,130	M16	steel parts in stainless steel
06601-51687	traffic blue	5	M16	23	23	30	32,5	49	12	33	72	77	110	126	15,5	26	0,130	M16	steel parts in stainless steel
